5. Carefully slide the six (6) 64-
1/2” tubes into open slots in the
area of the PVC Tees all the way
through the fabric until
they protrude out the
other end.
ASSEMBLY WITHOUT CEMENT:
NOTE: Two people and a rubber
mallet required.
6. Slip end of PVC tube into
appropriate end of the base Tee.
“Foot” the Tee and using the rubber
mallet, tap the other end of the tube
in until it bottoms out.
Repeat with the other ve (5) tubes.
Assembly Instructions
© Oberon
TM
| All rights reserved. Page 4 of 10
Arc Curtain Cube
