REGULATORS
ALPHA 8 SECOND STAGE
© 2002 Design, 2005
OCEANIC ® Product Service Guide
Doc. 12-2805-r02 (8/19/10)
PG-2
CONTENTS
TROUBLESHOOTING ................................................................................................................................................................. 3
DISASSEMBLY PROCEDURE .................................................................................................................................................... 4
REASSEMBLY PROCEDURE ..................................................................................................................................................... 6
FINAL TUNING AND TESTING ................................................................................................................................................... 8
PARTS LIST AND EXPLODED VIEW DIAGRAM ..................................................................................................................... 11
SPECIFICATIONS
Torques
P/N 4330 INLET COUPLING 100 to 120 in-lbs
LP Hose 50 to 60 in-lbs
GENERAL PROCEDURES
REFER TO ...............................................................................................................................................................DOC. 12-2202
TOOLS REQUIRED
Standard Tools
Inch Pounds Torque Wrench
1/4” Open End Wrench
11/16” Open End Wrench
3/4” Open End Wrench
Standard Screwdriver - small
Cotton Swab (Q-Tip)
Specialty Tools
Oceanic approved Halocarbon Based Lubricant (See General
Procedure Doc. 12-2202 for approved list)
P/N 40.3367 Poppet Tool
P/N 40.9315 Intermediate Pressure Gauge
P/N 40.9510 In-line Adjustment Tool
P/N 40.9520 O-ring Tool Kit
P/N 40.9650 Universal Front Cover Tool
Opening Effort IP = 138 psi (9.5 bar)
Recommended Setup Range (Primary) 1.1 to 1.5 inches of Water
Recommended Setup Range (Octopus) 1.5 to 2.2 inches of Water
Acceptable Setup Range (Primary and Octopus) 1.0 to 2.5 inches of Water
