3-Bag Bamboo Laundry Sorter
Package Contents
Item# XBS1484
Assembly Instructions
STEP 1. Use screw nut (F) and screw (G) to connect bamboo canes (A) and (B) to form an X Shape. Use wrench
(L) to tighten. (Make sure screw nut (F) is on the same side with the smaller hole on the cane and NOT the big hole).
STEP 2. Keep the X bamboo canes standing up. Use screws (J) to connect the grid shelf (C) onto the bottom holes
of the X canes. Use screws (J) to connect the horizontal tubes (D) onto the top holes of the X canes. Use wrench (K)
to tighten all the screws. (Make sure screw (J) goes in through the side with the bigger hole on the X cane).
A. Bamboo
Cane x 2
B. Bamboo
Cane x 2
F. Screw Nut x 2
E. Wire
Handle x 6
G. Screw x 2
D. Horizontal
Tube x 2
Safety Information
1. Two adults are recommended for ease of assembly. Use care when handing.
2. Assembly recommended on a soft surface, such as carpet, to avoid scratching flooring finish.
3. Discard the black circular plastic pieces. These are used to separate the shelves for shipping purpose.
CAUTION: Do not allow children to climb or play in or
around the shelves.
C. Bottom
Grid Shelf x 1
I. Feet Leveler
Pre-Screwed x 4
H. Bag x 3
STEP 3. Insert wire handles (E) through the bag loops (H) and place onto the horizontal tube (D).
J. Screw x 8
K. L Wrench x 1
L. Wrench x 1
A
A
F
B
B
G
J
J
J
D
C
E
H
