SERIES

1. Make sure that your system is turned off and unplugged. Disconnect the AC

power cord from your old power supply.

2. Open your computer case, please refer to the direction in your case manual.

3. Disconnect all power connectors from the devices.

4. Remove the existing power supply and replace the new one into your computer

case using ONLY the screws provided.

NOTE: It is important to use the supplied screws to complete the PSU installation.

The use of other type of screws may result in damage to the OCZ power supply and

risk voiding the warranty.

5. Connect power connectors to your motherboard and peripheral devices.

A. Connect the 24PIN Main Power Connector to your motherboard.

B. Connect the 4 / 8PIN +12V Power Connector to your motherboard

as needed.

C. Connect the Peripheral 4PIN Power Connector to devices. SATA

connectors are for devices with Serial ATA interface.

D. Connect the Y type Floppy Drive Power Adapter to the floppy as

needed.

E. Connect the PCI-E + 12V Power Connector(s) to the PCI-E graphics

card(s). Please consult your graphics manual for details if needed.

6. Close your computer case, connect the power cord to the power supply unit,

and then set the “I/O” switch of the power supply unit to “I” position.

7. You are now ready to start your computer.

POWER SUPPLY INSTALLATION
