OCZ ZX series User Manual

06
SERIES
CONNECTORS
CONNECTOR
TYPE
(20+4) P MAINBOARD
4+4P (8P) CPU+12V
[detachable]
6+2P (8P) PCI-EXPRESS
[detachable]
SATA
MOLEX
FDD
DESCRIPTION
Native cable, 12V rail
supplied For new
generations of
ATX/EEB/CEB
server/workstation MB.
Native cable, 12V rail
supplied.
- In Combined Mode -
8 pin configuration
supports multi-CPU
server/workstation
systems and some single
extreme CPU system.
- In Split Mod -
4 pin configuration
supports certain sing
le
CPU systems. Some multi-
CPU workstation/server
system might also need
Modular cable/ socket,
12V rail supplied.
- In Combined Mode -
8 pin configuration
supports latest extreme
graphic cards, which
require 8 pin PCI
connector.
- In Split Mode -
6 pin configuration
supports most
performance PCI-E graphic
cards, which require 6 pin
PCI-E connector.
Modular cable/
socket, for SATA /
SAS drives.
Modular cable/ socket
, for
IDE / SCSI / SAS drives or
some AGP graphic cards
w/ traditional 4P power
socket.
Modular cable/ socket, for
floppy drive or certain
add-on card.
QUANTITY
CONNECTOR
TYPE
DESCRIPTION
QUANTITY
12
6 [ 1000 W model ]
4 [ 850 W model ]
6 [ 1250 W model ]
12 [ Up to 12 MAX. ] 9 [ Up to 9 MAX. ]
1
