Throttle System
Throttle Freeplay Adjustment
Access the throttle cable
adjuster through the right front
1. Slide the cable adjuster
boot off the cable adjuster.
2. Squeeze the end of the rubber
boot and slide it far enough
to expose the end of the inline
3. Loosen the adjuster lock nut.
4. Move the cable adjuster until
1/16" to 1/8" (1.5-3mm) of freeplay
is achieved at the throttle pedal.
See page 61. While adjusting,
lightly flip the throttle pedal up and
6. Apply a small amount of grease
to the inside of the boot and slide
it over the cable adjuster to its
