NOTE: Change oil as many times as
necessary. until there is no whitish
appearance in engine oil. Check gearbox oil.
Replace oil if contaminated with water.
Replace oil of front differential.
Check vent tubes. Clean if required.
Lubricate front and rear suspensions and
propeller shaft joints. Refer to FRONT AND
REAR SUSPENSIONS.
Test drive to confirm proper operation.
AIR INTAKE SYSTEM
GENERAL
NOTICE: Never modify the air intake system.
Otherwise, engine performance
degradation or damage can occur. The
engine is calibrated to operate specifically
with these components.
AIR FILTER
For air filter servicing, refer to PERIODIC
MAINTENANCE PROCEDURES subsection.
AIR FILTER HOUSING
Removing Air Filter Housing
Release clamps and remove air filter cover
and filter.
1. Air filter cover
2. Latches
3. Duck bill valve
The filter fits tightly over the outlet
tube and there will be some initial
resistance.
Gently move the end of the filter back and
forth to break the seal, then rotate while
pulling straight out.
Avoid knocking the filter against the
housing.
Installing Air Filter Housing
For installation, reverse the removal
procedure but pay attention to the
following.
Align installation marks on throttle body, air
box and housing vent hose and make sure
below is not crushed.
Do not over torque.
