Remove the front drive
Remove the three installation brackets of
the front drive and unload the four bolts of
the front drive shaft after the plug, move a
certain distance forward, withdraw the front
drive shaft, take out the front reducer from
the right side of the body for maintenance.
Note: Removal of the front drive does not
require removal of any bolts of engine and
front upper swing arm.
Re-installation
Conduct installation based on reversed
sequence of dismantling.
