Operating Instructions and Parts Manual 24829
3/22
2022 OEMTOOLS
®
1,250 LB. LARGE ENGINE STAND
Figure Description Qty.
1 Main Post 1
2 Side Legs 2
3 Rear Frame 1
4 M12 x 25 Bolt 8
5 M12 Washer 16
6 M12 Nut 14
7 M12 x 25 Bolt 2
8 Mounting Plate 1
9 Locking Pin 1
10 Mounting Arms 4
11 M12 x 50 Bolt 4
12 M12 Large Flat Washer 4
13 Handle 1
14 Rear Wheels 2
15 Front Caster Assembly 2
16 M12 x 70 Bolt 2
17 Bushing 2
18 Spacer 4
19 M8 x 16 Bolt 8
20 M8 Nut 8
PRODUCT LAYOUT PARTS LIST
