Section 2: CATALOG NUMBERING SYSTEM
ETR-9200-
Signal Input
1 Thermocouple J, K,
T, E, B, R, S, N
2 RTD PT100 ohms,
Alpha = .00385/DIN
3 RTD PT100 ohms
Alpha = .00392/JIS
4 Other Voltage
(up to 10VDC)
or current
(up to 20mA)
Control Output
1
None
2 Relay rated
3A/240VAC resistive
3 Pulsed voltage to
drive SSR, 3-32VDC
4 Triac rated
1A/240VAC
5 Isolated 4-20mA
linear
6 Isolated 0-20mA
linear
7 Isolated 0-10VDC
linear
8 Special order
Alarm Outputs
1
None
2 With alarms A1 and
A2, relays rated
3A/240VAC resistive
3 SSR,3-32VDC
4 Special Order
Example:
ETR-9200-1221
• Thermocouple type*
J, K, T, E, B, R, S, N
• Relay Output
• With Alarm Option
* NOTE: True universal input can be
re-programmed in field
□ □ □
1
4
1 2
3
Sensor Sensor
Sensor Input Type Max. Range F°
Accuracy F°
Max. Range C°
Accuracy C°
J Iron/Constantan –58 to 1832°F±3.6°F –50 to 1000°C±2°C
K Chromel/Alumel –58 to 2500°F±3.6°F –50 to 1370°C±2°C
T Copper/Constantan –454 to 752°F±3.6°F –270 to 400°C±2°C
E Chromel/Constantan –58 to 1382°F±3.6°F –50 to 750°C±2°C
B Pt-30%RH/Pt-6%RH 32 to 3272°F±5.4°F 0 to 1800°C±3°C
R Pt-13%RH/Pt 32 to 3182°F±3.6°F 0 to 1750°C±2°C
S Pt-10%RH/Pt 32 to 3182°F±3.6°F 0 to 1750°C±2°C
N Nicrosil/Nisil –58 to 2372°F±3.6°F –50 to 1300°C±2°C
RTD PT 100 ohms (DIN) –328 to 752°F ±0.72°F –200 to 400°C±0.4°C
RTD PT 100 ohms (JIS) –328 to 752°F ±0.72°F –200 to 400°C±0.4°C
Linear 4 - 20 mA –1999 to 9999 ±0.05% –1999 to 9999 ±0.05%
Linear 0 - 20 mA -1999 to 9999 ±0.05% -1999 to 9999 ±0.05%
Linear 0 - 1 VDC -1999 to 9999 ±0.05% -1999 to 9999 ±0.05%
Linear 0 - 5 VDC -1999 to 9999 ±0.05% -1999 to 9999 ±0.05%
Linear 1 - 5 VDC -1999 to 9999 ±0.05% -1999 to 9999 ±0.05%
Linear 0 - 10 VDC -1999 to 9999 ±0.05% -1999 to 9999 ±0.05%
Maximum Temperature Ranges:
Chromel
®
and Alumel
®
are Registered Trademarks of Hoskins Manufacturing Company.
NOTE: If a low voltage power source is used, place a number ”3” before
the Signal Input for 20-32VAC/VDC operation.
Communications
1 None
2 RS-485
3 Retransmission
4 RS-232C
To Next Page
