21
22
1
2
23
22
21
3
23
1
26
4
2
6
Attach Undercarriage (2) to Poly Body (1) and tighten with
hardware (21,22,&23) as shown.
Attach Front Support (3) loosely to Poly Body (1) with hardware (21,22,&23) as shown.
Insert Axle (4) into Undercarriage (2) halfway as shown and center Spacer (26)
inside Swivel Clevis (6).
DO NOT
TIGHTEN
HARDWARE
AT THIS TIME
4
Assembly Instructions
1
3
2
To Next Page
