OHIOSTEEL 48CP - Step 1: Attach Hitch; Step 2: Attach Center Plates; Step 3: Install Axle and Foot Lever

23
24
4
7
15
27
29
28
3
10
13
1
31
5
30
29
28
NOTE HOLE LOCATION
Attach Hitch to Top Plate and tighten hardware.
Attach Center Plates to Top Plate and tighten hardware.
Insert Bushings to hold Spool in place.
Hold Foot Lever in place and slide Axle into position, then tighten hardware.
Install Tube Plugs into Foot Lever using a mallet if necessary.
3
Assembly Instructions
1
3
2
