8
RXF34/RXF36 50-HOUR SERVICE
17
16. Inject 5 ml of fork lubrication uid in spring fork leg and 5 ml in
damper fork leg.
17. Reinstall the rebound adjuster nut, knob and screw and tight
-
en to 10 Nm. Ret the lower valve nut and washer and tighten to 10
Nm.
18. Adjust the rebound setting.
See Owner’s Manual/Mounting Instructions for more information.
19. Go out and enjoy your ride!
18
16
5 ml
5 ml
