TOOLS
1 2 3
4 5 6
7 8 9
10
13
16
14
17
15
18
11 12
1 00146-01 Assembly lubricant – Red grease
2 00716-01 Snub nose
3 00720-02 Measure Pin (6mm)
4 00727-02 Soft jaws 10/12
5 00727-09 Soft jaws 28/36
6 00797-08 Top cap tool
7 01460-68 Dividing piston positioning tool (tube length 32mm)
8 01765-03 Pull-up tool (length 300mm)
9 01781-01 Gas lling device assy (gas needle housing 01779-02)
10 01797-05 Seal head tool 33.5 (compress top out spring)
11 01797-07 Seal head tool 36 (tighten with torque)
12 01797-09 Seal head tool 36 (long fangs)
13 01820-24 Filling machine assembly adaptor M4
14 01840-xx Öhlins Filling Machine (and Manual 07221-02)
15 01860-04 End cap tool
16 02810-01 Clip for 01765-03
17 04705-03 U-spanner 19mm
18 01309-01 Öhlins Front Fork uid
19 FGR1XX Spec. card
