CT-12 TECHNICAL SPECIFICATION
Full Range, Reflex Tuning.
8 Ohm, Minimum 5.7 ohm @ 286 Hz
450 Watts (continuous)
900 Watts (program) 1800 Watts (Peak 10 ms)
103 dB
129 dB (cont. max SPL / 1m), 135 dB peak
55 Hz - 20 kHz with active EQ
60° x 40°, Rotational
Design
Impedance
Power handling AES
Maximum power handling
Sensitivity 2.83V / 1m
Max SPL
Frequency response -3dB
Dispersion
450W @ 8 Ohm
Ohm DSP Solutions Mandatory
Min 2 x 4 mm
2
Preferred 2 x 6 mm
2
SYSTEM OPERATION
Recommended Amplification
System Controller
Speaker Cables
*technical specifications are preliminary and subject to confirmation
PRODUCT FEATURES
1 x 12” Low frequency driver
1 x 1.5” horn loaded compression driver
Passive, requires active EQ
2 x 4 pole Speakon Connectors
726 mm x 380 mm x 320 mm
28
30.2
Black
Available in white or Ral colours on request.
12 x mounting points, 6 to take flying eyes, 6 to take M8 bolt.
Components
Crossover
Connectors
Dimensions (H x W x D)
Weight (Kgs)
Shipping Weight (Kgs)
Colour
Options
Rigging
LF HPF LF LPF HF HPF
Without Sub
50 Hz Butt 18 dB Oc
--
With Sub
100Hz Butt 24 dB Oc
--
Bi-amp without Sub
-
--
Bi-amp with Sub
---
RECOMMENDED FILTER SETTINGS
Fitted as standard
Optional
Additional Descriptive Data
TH-1 Cast aluminium top hat
CPFK Recessed flying points
CFEK Set of three flying eyes
ABS-1 Adjustable stand bracket
ABT-1 Adjustable threaded spigot bracket
LWB Large wall bracket
SS-1 Speaker stand
TP-1 Adjustable threaded pole
18 mm Birch Ply construction, with durable scratch resistant black
textured paint finish, kick-proof steel grill with stainless steel Ohm logo.
HARDWARE
