OHVALE GP-2 - Engine Oil Management; Oil Quantity Specifications; Oil Level Check Procedure

01/04/2021
Page 6
7. ENGINE OIL
Use engine oil 4T 10W40 only.
7.1. OIL QUANTITY (with engine completely empty)
ENGINE
QUANTITY ( total )
110 A
1100 cc
110 4S
850 cc
160 4S
1100 cc
190 DAYTONA
1001 cc
7.2. ENGINE OIL LEVEL CHECK
110 A model
• Start the engine and let it run at the minimum rotation speed for 3/5 min, then turn it off.
• After 2/3 min. place the vehicle on a flat surface in vertical position (without stand).
• Remove the filler cap placed on the right side of the engine, clean the level rod and
insert it in again without screwing it.
• Remove level rod and check the level ( the oil should be nearly the max marker).
Eventually, add the correct amount of oil in order to restore the correct level.
• Screw the cap until it’s firmly close.
110 4S e 160 4S model
• Start the engine and let it run at the minimum rotation speed for 3/5 min, then turn it off.
• After 2/3 min. place the vehicle on a flat surface in vertical position (without stand).
• Remove the filler cap placed on the right side of the engine, clean the level rod and insert
it in again screwing it in completely.
• Remove level rod and check the level ( the oil should be at 5 mm [ 0.20 in ] from max
marker). Eventually, add the correct amount of oil in order to restore the correct level.
• Screw the cap until it’s firmly closed.
190 Daytona model
• Start the engine and let it run at the minimum rotation speed for 3/5 min, then turn it off.
• After 2/3 min. place the vehicle on a flat surface in vertical position (without stand).
• The oil level must be between the half and the top of the porthole.
• To restore the correct oil level, open filler cap placed on the right side of the engine
and add the necessary quantity of oil.
NOTE Overfilling oil or using the vehicle with insufficient oil can cause engine damage. It
is recommended not to use different types of engine oil.
