Main Unit Components (Figure 1)
1.
Power “on” LED
2. Reflow head “X” axis release button
3. Camera & Lighting assembly
4. Reflow head “up” button
5. Reflow head “down” button
6. Type K thermocouple inputs (3)
7. “Y” Axis micrometer
8. Command "Enter" button
9. “X” Axis micrometer
10. Open Frame adjustable printed circuit board holder
11. Reflow head “Y” axis release button
12. Component theta control
Figure 1
12
2
4
10
7
9
3
6
5
1
11
8
