Main Unit Components, Rear View (Figure 2.1 & 2.2)
1. RS-232 connector.
2. Composite video output.
3.
Main air connector for reflow head.
4. Nitrogen / Shop air input connector.
5.
Fuse Holder (Version 1) / Breaker (Version 2)
6.
AC Power input.
7. Reflow head electrical connector
8.
Main power switch.
Figure 2:2 (Version 2)
Figure 2:1 (Version 1)
8
7
5
6
1
4
3
2
1
2
3
4 5
6
7
8
