www.okinternational.com - 15 - P/N 7000-1370, Revision B
Click Next
10. Vision – Adjust camera parameters; lamp intensity, focus, zoom and iris controls.
Click Next
11. Camera – Return camera to home position to continue.
12. Component – Set the height for placing the component.
• Coarse – action buttons
• Fine – Up / Down software buttons on screen or the action buttons
Move head down to place position.
Click Next
Adjust the nozzle height.
Click Next
13. “Create Profile” – This screen allows the setup of the air flow and heating
parameters of the reflow cycle.
• Select the airflow rate: High, Med, Low/.
• Grab and move the temperature and time bars to the desired positions to create
the thermal characteristics of the profile.
Click Start to run profile or Next to continue without running the profile.
• The display will prompt you to “Hit action buttons to move reflow head to the
home position” the head will move at high speed to the top position. A window
automatically opens to allow for the profile to be saved.
14. Save – This allows you to run the new process in verify mode, permitting you to
change the settings while it runs and then save the profile. Or you can just save
the process.
Process setup – New Process – Removal
1. Process Info
2. Software prompts “Select Yes” to attach vacuum cup and reflow nozzle during
process Run and creates a custom user’s prompt.
3. “Pull out camera to continue”
4. Adjust camera settings; focus height, zoom, lamp intensity, and iris controls.
Click Next
5. “Return camera home to continue.”
6. Adjust the reflow nozzle height. “Using action buttons move nozzle into position
on PCB.” Click Next
7. Set method of lifting. Click Next
