www.okinternational.com - 16 - P/N 7000-1370, Revision B
Please do not use your hand to catch the component.
Even after the cooling cycle the component can be extremely hot.
8. Retract Vacuum Tube
9. Raise head
10. Do not remove
11. Select airflow rate and make adjustments to the profile settings in the profile
window. Click Next
12. L M H
13. ”Hit action buttons to move reflow head to the home position.” Click Next
14. Start To verify your new process.
15. When completed click Next. Software prompts select Next
16. Select Next to release component. Window opens to save profile
