15. For a final test, lower the mirror to the reverse mounted gun-sight tool, release
the mirror, and attempt to pick-up the component. If aligned correctly, the steel
vacuum pipette will pick up the component. Adjust as needed.
16. When the calibration mirror is parallel to the reverse mounted gun sight tool,
tighten the lock screws. Reassemble the front cover and proceed to the APR
Head to Pick-Up Point Alignment Procedure Head.
