3. Pull out slide and loosen pick-up point lock-down screws. Lock Down Screws are
located opposite each other on the camera for optimum adjustment.
4. Adjust side to side as needed and front to rear as needed with mirror near the
pick up point as a gauge.
Lock Down Screw
Movement
This side
does not
adjust.
Side to Side Adjustment
