10 OKIPAGE 8w Lite
• Connect the interface cable to the printer first,
then connect to the computer.
Parallel data connection
1. Connect the interface cable to the parallel socket
(1) on the printer.
USB cable connection
The printer comes with a USB interface as standard.
This requires a Type A to Type B cable, not more than
5m in length.
1. Connect the Type B (square) connector on the
cable to the USB interface connector at the rear of
the printer (2).
2. Connect the Type A (small, flat) connector on the
other end of the cable to the host computer’s USB
port.
See ‘Printer driver installation’ for further information
on printer installation.
Power connection
1. Connect the power cable into the power socket
(3) on the printer, then into a grounded outlet.
2. Switch the printer on using the main power
switch (4).
4
3
1
2
