7
STEP 1: Remove the 6 preinstalled bolts (C) from the cross posts (F).
STEP 2: Arrange leg post (D), U bar (E),
and cross post (F). Cross post (F) should be
attached to the hole furthest away from the
black end cap on leg post (D).
See Fig. 1
STEP 3: Build the other side of the cart using leg
post (D) and 2 cross posts (F) into the same
shape as in Step 2.
STEP 4: Connect each side of the cart frame
together with the final cross post (F), secure cross
post to legs (D) using bolts (c).
STEP 5: Place washer (b) between the wheel and U bar (E), insert bolt
(a) through tire, place washer (b) on the other end of the bolt. Repeat
for the remaining tire.
STEP 6: Insert a screw driver through the hole on
tool (I) and twist to tighten. If the wheels do not
spin, loosen the bolts slightly. See Fig. 2.
