6-56
Fuse Usage
7C Not Used
8C Not Used
9C Battery, Radio, Cluster
1D Ignition (Run/Crank),
Chime, Cluster
2D Spare
3D Not Used
4D Not Used
5D Base A/C
6D Fog Lamps
7D Transaxle
8D Radio
9D Not Used
1E Auxiliary Outlet(s)
Fuse Usage
2E
Air Bag System, PASS
-Key II
R
3E Ignition (Off/Unlock)
4E Not Used
5E Rear Defog
6E Not Used
7E
Misc Engine (Non
-OBD II)
8E Wipers, Washer
9E Not Used
Passenger’s Side Fuse Block
Additional fuses are located in the relay center, on the
passenger’s side, below the instrument panel. You must
remove the sound insulator on the right side of the
passenger footwell to replace these fuses.
Since replacing these fuses is difficult, we recommend
that you see your dealer if you need one replaced.
