29
(17) TILTING FRAME CONTROL LEVERS
The tilting frame is intended as an aid for maintenance and servicing works and as protection of the user
against tree and bush branches. The control levers serve to set the frame to one of the following three
positions:
1. Work
2. Service
3. Auxiliary for handling the mower
The individual positions are set using quick coupler levers on the sides of the frame.
THE TILTING FRAME DOES NOT SERVE AS MOWER ROLL-OVER PROTECTION FOR
THE USER!
