42
Perform the replacement as follows:
}Place the jack underneath the front or rear bumper near to the
wheel which you wish to replace. For model AC 92-23 4x4 – always
place the jack against the frame - do not lean it on the transmission,
this could damage it!
}Keep lifting the mower until the wheel, which you wish to change
no longer touches the ground.
}Remove the protective cover from the wheel.
}Using a suitable screwdriver remove the retaining ring and remove
the washer.
}Pull the wheel off the shaft.
When reattaching the wheel proceed in the reverse sequence to its removal. Before attaching the wheel
clean all parts and lightly grease the shaft with a plastic lubricant. Especially for wheels on the rear
axle this lubrication is essential for the subsequent removal of the wheel. In the event that
lubrication is not performed the subsequent attachment may be very difficult.
When attaching the rear wheel pay attention to the mutual alignment of the pin on the shaft and the
groove on the wheel.
Finally, check the tyre pressure.
6.3.12 REPAIRING A TYRE PUNCTURE
The mower is equipped with tubeless tyres. In the event of a puncture, have it repaired at a specialised
tyre repair shop or at an authorised Seco mower service centre.
6.3.13 MAINTENANCE OF THE HYDROSTATIC TRANSMISSION
6.4
For the reliable operation of the transmission it is necessary to maintain the correct oil level.
In the event of problems with the transmission immediately seek the help of an authorised
service centre, there is a risk of serious damage to the transmission.
Mower model Oil type Oil level
92 EVO SAE 10W-40, API CD At least to half the height of the equalisation tank
92 EVO 4x4 SAE 5W-50 synthetic oil
Between the marks on the dipstick in the tank cap
(total oil volume in the hydraulic system is 6l)
In the event of problems with the transmission immediately seek the help of an authorised
service centre, there is a risk of serious damage.
