23
EN
USAGE
WARNING: First of all read the
Safety Warnings and then this
Specic Manual
.
> PUT INTO SERVICE
See g.
A
> STARTING UP
See g.
B
> HIGH PRESSURE LANCE
See g.
D
> DETERGENT SUCTION
See g.
E
> HIGH PRESSURE HOSE
See g.
F
> WATER SUPPLY
Water supply collection
WARNING (symbol): machine not
suitable for connection to the potable
water mains.
The cleaner can only be connected to
the water mains if the water mains is
separated by a backow preventer.
Make sure that the hose is at least Ø
13mm-1/2 inch and that it is reinforced.
Fuse 16 A
Maximum inlet water temperature 40 °C - 98 °F
Minimum inlet water temperature 5 °C - 41 °F
Minimum inlet water flow 900 l/h - 15 l/min - 172 US gph
Maximum inlet water pressure 1 MPa - 10 bar - 145 psi
Minimum inlet water pressure 0,1 MPa - 1 bar - 14,5 psi
Recoil of cleaner gun 10 N
Sound pressure level - Uncertainty (*) 81 dB(A) - 0,7 dB(A)
Sound power level granted 96 dB(A)
Operator arm vibrations - Uncertainty (*) 1,5 m/s² - 0,5 m/ s²
Lenght x width x height 310 x 280 x 650 mm - 12,2 x 11 x 25,6 in
Detergent tank capacity 0,7 l - 0,18 US gal
Detergent bottle capacity
-
(*) Measurements taken in compliance with EN 60335-2-79
All features and technical specifications are only indications. The Manufacturer reserves the right to modify
the appliance as it deems necessary.
For other technical data, refer to the identication plate on the
machine (see data interpretation on page 15 of this manual).
MAIN FEATURES AND TECHNICAL SPECIFICATIONS
