1.2.2 Names and functions of the product configuration
1.2.2.1 Body
NO
Name
`Description
A
Display LED
LED displaying the device status
B
측정 LED
LED lighted when the light source operates upon measurement
C
Charger LED
LED lighted upon charging
D
Button (ON/OFF &
measurement)
Button that operates after turning ON/OFF the instrument’s
power supply
E
LED Source
Multi-wavelength light source for measurement of abdominal
fat
F
PD Sensor
Sensor receiving multi-wavelength optical signals transmitted
from the abdomen
G
Charging PORT
Port for charging of the embedded battery
