Oliver 2019 - Tailstock and Related Components; Tool Rest and Banjo; Safety

8 | Page Oliver Machinery 2019 Lathe
Tailstock
Tailstock Taper
MT #2
Tailstock Quill Travel
4-3/8”
Tailstock Quill Through Hole Size
3/8”
Tailstock Quill Thread
ACME 29 20-8teeth/INCH (Left-handed)
Lathe Bed
Main Bed Length
33-7/8”
Extension Bed Length
15”
Bed Gap Size
1-3/4”
Tool Rest and Banjo
Include Tool Rest Type
Cast Iron
Tool Rest Width
12”
Tool Rest Post Diameter
1”
Tool Rest Post Length
2-3/8”
Banjo Usable Length
11-3/4”
Banjo Base Height
2”
Banjo Overall Height
5-3/4”
Outboard Banjo Usable Length
16-3/4”
Outboard Banjo Base Height
3”
Outboard Banjo Overall Height
14-1/2”
Accessories
Spindle Center
Four-Prong Spur Center
Tailstock Center
Live Center
Faceplate
Two 6” Steel Faceplates
Safety
Sound Rating
74 dB (2’ Distance and Max RPM)
Others
Serial Number Location
On the lathe cabinet behind the tool rack.
Country of Origin
Taiwan
