3. Lay out both completed Floor
Frames as illustrated.
2. When correctly positioned, attach each joist with 4 - 2 1/2” screws (Part B) - 2 per end. Complete
Joist attachments for 2nd Floor Frame.
4. Align Floor Frames together as shown below. Screw sections together with 8 - 2 1/2” screws (Part B).
Alternate screw location. Use a wood clamp to keep frames together while screwing.
5. When completed, your floor footprint
should be 70” wide x 75” deep.
You can find the
Square Drive Bit
(Part A) for the
screws in with the
Hardware Kit Bag.
Front 70”
Door goes
on 70” side
