Page 8
7. Complete remaining
Corner Post/Wall attachments
following Steps 4-6.
8. To complete remaining Post and Side Wall
attachments, locate 3 Side Vertical Posts (Part R)
and 4 - 20 1/4” Wide Side Walls (Part E or F’s).
On solid, level ground such as a patio or deck lay
the pieces down as shown below. You will need
at least a 10’x10’ area. Place Side Vertical Posts
with their 2x3’s face down. (Vertical Posts are
made using a combination of 2x3’s/2x4’s). Place
Walls with Siding down as well.
Part R - Side Vertical Posts
Part E or F - 20 1/4” Wide Side Walls
2x4 facing up
2x3 facing down.
Top
