85. Continue attaching Rafters to Core Block
securing with 3” screws 2” from the top.
86. Complete all Rafter / Core Block
attachments.
87. Locate 8 Cupola Facia Pieces and place
against Rafter ends.
88. Position Rafter so it sits equally on both Rafter
ends. Also, use a straight edge to make sure Rafter
sits approx. 3/8” below rafter top. Attach Facia to
Rafter end with 2 - 2” screws per Facia.
89. Position and secure second Facia Piece.
90. Place and secure all Facia Pieces as
per Step 88.
Straight Edge
Facia sits below Rafter
Rafter Top
Toll Free 1-888-658-1658 www.outdoorlivingtoday.com sales@outdoorlivingtoday.com
Page 30
Important- angle
screw up into the
heart of Rafter
end.
To Next Page
