Technical Data
Laminator A 230 Plus / A 330 Plus
22
The lamination result is not as good
as expected - the laminated foil is
not completely transparent or is
wavy, or the laminated material is
damaged.
Use only laminating foils that meet the
requirements in the Technical Data.
Do not exceed the maximum thickness of
the laminated material and foil.
Laminate the same foil again to improve
the lamination result.
Make sure you do not hot-laminate heat-
sensitive material.
If you use thick laminating foil
(100 μ or 125 μm), let the laminator heat
up for longer.
Technical Data
Laminating system: Hot-roller
Working width 230 mm (A 230 Plus), 330 mm (A 330 Plus)
Laminating temperature Room temperature: max. 35°C
HOT: 97 - 105°C
Laminating width (max.) 230 mm (A 230 Plus), 330 mm (A 330 Plus)
Warm-up phase (seconds) 120 (A 230 Plus), 180 (A 330 Plus)
Foil thickness 80 - 125 micron
Laminating speed: 400 mm/min.
Automatic switch-off
in case of overheating Yes
Indicator lights 2, Ready and Power
Cool down phase approx. 15 min.
Rollers 2
Power supply 220 - 240 V, 50 Hz, 1.3 A (A 230 Plus)
220 - 240 V, 50 Hz, 1.76 A (A 330 Plus)
Power consumption 305 W (A 230 Plus), 405 W (A 330 Plus)
Dimensions 366 x 146 x 66 mm (A 230 Plus)
466 x 146 x 66 mm (A 330 Plus)
Weight approx. 855 g (A 230 Plus),
approx. 1260 g (A 330 Plus)
Suitable materials
(hot lamination)
Non-heat-sensitive material up to a total
thickness of 0.5 mm
Suitable materials
(cold lamination)
Heat-sensitive material up to a total thickness
of 0.5 mm
