Drill Guide Cut out this handy drill guide for easy installation.
100DR — INSTALLATION INSTRUCTIONS
Installation Template:
100DR, 100B, 100M
Drill four 1/16” diameter
holes from the inside
Drill a 7/8”
diameter hole
from the outside
