Olympus FE-4020 User Manual

4 EN
Using the Menu
Using the Menu
Use the menu to change camera settings such as the shooting mode.
Press the m button to display the function menu. The function menu can be used to set frequently
used shooting and playback functions such as shooting mode.
PERFECT FIX
EDIT
ERASE
SETUP
SLIDESHOWSLIDESHOW
Use FG to select a menu and press
the H button.
44
PP
0.00.0
AUTO
WB
AUTO
WB
AUTO
ISO
AUTO
ISO
14 M
PROGRAM AUTOPROGRAM AUTO
Shooting Playback
Selected option
To select the shooting mode
Use HI to select a shooting mode and press
the H button.
To select the function menu
Use FG to select a menu and use HI to
select a menu option. Press the H button to
set the function menu.
o [SETUP]
menu
Function
menu
Shooting
mode
In the [SETUP] menu, various camera functions can be set,
including shooting and playback functions not displayed in the
function menu, and other settings such as date, time and screen
display.
1 Select [SETUP] and then press the H
button.
The [SETUP] menu is displayed.
FINE ZOOM OFF
R OFF
AF MODE FACE/iESP
MENU OK
SETEXIT
1
2
3
ICON GUIDE
IMAGE STABILIZER ON
ON
COMPRESSIONCOMPRESSION NORMALNORMAL
2 Press H to highlight the page tabs. Use
FG to select the desired page tab and
press I.
1
2
3
OFF
MENU OK
SETEXIT
POWER SAVE
Page tab
1
2
3
MENU OK
SETEXIT
OFFOFFPOWER SAVEPOWER SAVE
Submenu 1
3 Use FG to select the desired submenu 1
and then press the H button.
1
2
3
MENU OK
SETEXIT
POWER SAVEPOWER SAVE OFF
1
2
3
OK
SET
MENU
BACK
OFFOFFPOWER SAVEPOWER SAVE
POWER SAVE
ON
OFFOFF
Submenu 2
●
4 Use FG to select the desired submenu 2
and then press the H button.
Once a setting is selected, the display returns
to the previous screen.
There may be additional operations.
“Menu Settings” (p. 27 to 36)
1
2
3
MENU OK
SETEXIT
ONPOWER SAVEPOWER SAVE
5 Press the m button to complete the
setting.
Some functions cannot be used in some
shooting modes. In such cases, the
following message is displayed after
setting.
1
2
3
FINE ZOOM OFF
R OFF
MENU OK
AF MODE FACE/iESP
COMPRESSIONCOMPRESSION NORMALNORMAL
SETEXIT
ICON GUIDE
IMAGE STABILIZER ON
ON
CONFLICTING SETTINGS
●

Olympus FE-4020 Specifications

General

Megapixel	14 MP
Camera type	Bridge camera
Sensor type	CCD
Image stabilizer	Yes
Image sensor size	1/2.3 \
Image formats supported	JPEG XR
Maximum image resolution	4288 x 3216 pixels
Still image resolution(s)	3264 x 2448\\r 2560 x 1920\\r 2048 x 1536\\r 1600 x 1200\\r 1280 x 960\\r 640 x 480\\r 1920 x 1080
Optical zoom	4 x
Focal length range	26 - 105 mm
Maximum aperture number	5.9
Minimum aperture number	2.6
Maximum focal length (35mm film equiv)	105 mm
Minimum focal length (35mm film equiv)	26 mm
Normal focusing range	0.6 – infinity m
Auto focusing (AF) modes	Spot Auto Focus, Tracking Auto Focus
Super Macro focusing range	0.04 – infinity m
Macro focusing range (tele)	0.6 - ∞ m
Macro focusing range (wide)	0.2 - ∞ m
Normal focusing range (tele)	1 - ∞ m
ISO sensitivity	100, 200, 400, 800, 1600
Light exposure modes	-
Fastest camera shutter speed	1/2000 s
Slowest camera shutter speed	4 s
Flash modes	Auto, Fill-in, Red-eye reduction
Flash range (tele)	0 - 2.11 m
Flash range (wide)	0 - 4.79 m
Flash exposure correction	±2EV (1/3 EV step)
Power source type	Battery
HD type	Not supported
Video formats supported	AVI
Maximum video resolution	- pixels
Memory slots	1
Internal memory	18 MB
Compatible memory cards	SD, SDHC
Maximum memory card size	8 GB
Display diagonal	2.7 \
Viewfinder type	Not available
HDMI	No
USB version	2.0
Scene modes	Candlelight, Cuisine, Documents, Fireworks, Night, Night portrait, Party (indoor), Pet, Portrait, Self-portrait, Sports, Sunset, Landscape (scenery)
White balance	Auto, Daylight, Fluorescent, Tungsten
Shooting modes	Auto, Movie, Scene
Self-timer delay	2, 12 s
Windows operating systems supported	Windows 2000 Professional, Windows 7 Home Basic, Windows 7 Home Basic x64, Windows 7 Home Premium, Windows 7 Home Premium x64, Windows 7 Professional, Windows 7 Professional x64, Windows 7 Starter, Windows 7 Starter x64, Windows 7 Ultimate, Windows 7 Ultimate x64, Windows Vista Business, Windows Vista Business x64, Windows Vista Enterprise, Windows Vista Enterprise x64, Windows Vista Home Basic, Windows Vista Home Basic x64, Windows Vista Home Premium, Windows Vista Home Premium x64, Windows Vista Ultimate, Windows Vista Ultimate x64, Windows XP Home, Windows XP Home x64, Windows XP Professional, Windows XP Professional x64
Battery life (CIPA standard)	180 shots
Product color	Pink
Storage temperature (T-T)	-20 - 60 °C
Operating temperature (T-T)	0 - 40 °C
Storage relative humidity (H-H)	10 - 90 %
Operating relative humidity (H-H)	30 - 90 %

Weight and Dimensions

Depth	22.8 mm
Width	95 mm
Height	56.2 mm
Weight	128 g
