Olympus FE-5020 User Manual

11 EN
3
Notch
Contact area
Insert the card straight until it clicks into
place.
Do not touch the contact area directly.
1
1
2
1
2
4
FE-5020/X-935 FE-4010/X-930
This camera allows the user to take pictures
using the internal memory even when
no xD-Picture Card (sold separately) is
inserted. “Using an xD-Picture Card” (p. 47)
“Number of storable pictures (still pictures)/
Continuous recording length (movies) in
the internal memory and xD-Picture Card”
(p. 48)
To remove the xD-Picture Card
12
Press the card in until it clicks and comes
out slightly, then grab the card and pull it
out.
Loading the battery and
the xD-Picture Card™ (sold
separately) into the camera
Do not insert anything other than an
xD-Picture Card or the microSD Attachment
into the camera.
11
1
1
22
Battery/card compartment cover
Battery/card
compartment
lock
FE-5020/X-935 FE-4010/X-930
2
Battery lock knob
Insert the battery by putting in the ▼ marked
side fi rst, with the B marks toward the
battery lock knob.
Damage to the battery exterior (scratches,
etc.) may produce heat or an explosion.
Insert the battery while sliding the battery
lock knob in the direction of the arrow.
Slide the battery lock knob in the direction
of the arrow to unlock, and then remove the
battery.
Turn off the camera before opening the
battery/card compartment cover.
When using the camera, be sure to close
the battery/card compartment cover.

Olympus FE-5020 Specifications

General

Megapixel	12 MP
Camera type	Compact camera
Sensor type	CCD
Image stabilizer	Yes
Image sensor size	1/2.3 \
Maximum image resolution	3968 x 2976 pixels
Filter	RGB
Digital zoom	4 x
Optical zoom	5 x
Combined zoom	20 x
Focal length range	4.3 - 21.5 mm
Number of aspheric elements	3
Interface	USB
Digital SLR	No
Dimensions (WxDxH)	92.7 x 55.8 x 24.7 mm
Aperture range (F-F)	3.3 - 5.8
Camera shutter speed	1/4 - 1/1000 s
Effective sensor resolution	12200000 pixels
Focal length (35mm film equivalent)	24 - 120 mm
Focus adjustment	Auto
Auto focusing (AF) modes	Spot Auto Focus
Closest focusing distance	0.01 m
Macro focusing range (tele)	0.6 - ∞ m
Macro focusing range (wide)	0.15 - ∞ m
Manual focusing range (tele)	1.0 - ∞ m
Light metering	Spot
ISO sensitivity	64, 100, 200, 400, 800, 1600, 3200
Motion JPEG frame rate	30 fps
Maximum video resolution	640 x 480 pixels
Display diagonal	2.7 \
Display resolution (numeric)	230000 pixels
USB version	2.0
Scene modes	beach, Candlelight, Cuisine, Documents, Fireworks, Panorama, party (indoor), Portrait, self-portrait, Sports, Sunset, Landscape (scenery)
Image editing	resizing, rotating, trimming
Photo effects	Black&White
White balance	auto, Cloudy, daylight, Fluorescent, Tungsten
Camera playback	movie, slide show
Self-timer delay	12 s
Playback zoom (max)	1.1 x
Product color	White
Battery type	LI-42B
Flash modes	auto, fill-in, Red-eye reduction
Compatible memory cards	xd

Weight and Dimensions

Depth	24.7 mm
Width	92.7 mm
Height	55.8 mm
Weight	107 g
