Olympus HLD-7 - EN INSTRUCTIONS; Names of Parts; Specifications; Safety Precautions

EN 5
INSTRUCTIONS
Thank you for purchasing this Olympus product. To ensure your safety, please read this instruction
manual before use, and keep it handy for future reference. This product is for use with Olympus cam-
eras only. For information on compatibility and safe battery use, see your camera manual.
EN
Safety Precautions
Inserting the Battery (Fig. 3)
Names of Parts (Fig. 4)
1 Shutter button
2 Front dial
3 Attachment wheel
4 Vertical shooting lock
5 B-Fn2 button
6 B-Fn1 button
7 Rear dial
8 AC connector cover
Specifi cations
Power source Battery : BLN-1 Li-ion battery ×1
AC power source : AC-3 AC adapter
Dimensions (W×H×D) : Approx. 128.5 × 48.2 × 57.3 mm
(5.1 × 1.9 × 2.3 in.)
Weight (excluding battery and
terminal cover)
: Approx. 235 g (8.3 oz.)
Splash resistance
(when attached to camera)
: Type Equivalent to IEC Standard
publication 529 IPX1 (under OLYMPUS
test conditions)
• Be sure to put the PBH cover (a) on the camera when
the HLD-7 is not attached.
• Use the specifi ed power sources only. Failure to observe
this precaution could result in injury, explosion, or product
malfunction.
• Do not operate the attachment wheel with your
fi ngernails. Failure to observe this precaution could result
in injury.
• Use within the operating temperature specifi ed for your
camera.
• Do not use or store this product in areas exposed to high
levels of dust or humidity.
• Do not touch the contacts.
• Remove dirt from the contacts and other areas with
a soft, dry cloth. Do not use damp cloths or thinner,
benzene, or other volatile cleaners.
