INSTRUCTIONS
Thank you for purchasing this Olympus product. To ensure your safety, please read this instruction
manual before use, and keep it handy for future reference. This product is for use with Olympus cam-
eras only. For information on compatibility and safe battery use, see your camera manual.
Connecting the HLD-8G (Fig. 1-1, 1-2)
Connecting the HLD-6P (Fig. 2-1, 2-2)
Inserting the Battery (Fig. 3)
Names of Parts (Fig. 4)
1
Shutter button
2
Front dial
3
Attachment wheel
4
Vertical shooting lock
5
B-Fn2 button
6
B-Fn1 button
7
Rear dial
8
Headphone jack cover
9
AC connector cover
Specifi cations HLD-8G HLD-6P
Power source
Battery
:
— BLN-1 Li-ion battery ×1
AC power source
:
— AC-3 AC adapter
Dimensions (W×H×D) :
Approx. 126.3 × 73.6 × 59.5 mm
(5.0 × 2.9 × 2.3 in.)
Approx. 117.8 × 31.3 × 56.4 mm
(4.6 × 1.2 × 2.2 in.)
Weight (excluding battery and terminal cover) :
Approx. 108.0 g (3.8 oz.) Approx. 126.2 g (4.5 oz.)
Temperature/Humidity
(operation)
:
–10 °C - 40 °C (14 °F - 104 °F)/30% - 90%
Splash resistance (when attached to camera) :
Type Equivalent to IEC Standard publication 529 IPX1 (under OLYMPUS
test conditions)
Safety Precautions
• Be sure to put the PBH cover (a) on the camera when the HLD-8 is not attached.
• Use the specifi ed power sources only. Failure to observe this precaution could result in injury, explosion, or product malfunction.
• Do not operate the attachment wheel with your fi ngernails. Failure to observe this precaution could result in injury.
• Use within the operating temperature specifi ed for your camera.
• Do not use or store this product in areas exposed to high levels of dust or humidity.
EN
