Olympus OM-1 - Page 20

(5)
(6)
(7)
(8)
E-19
Make
fine
adjustment
on
the
alignment
of
the
Patch
of
8600
and
the
Scratched-Line
on
the
die-cast
by
adjusting
the
5
holes’
positions.
Tolerance:
0
-
0.3mm
(From
the
point
of
perfect
coincidence
with
the
Scratched-
Line
up
to
0.3mm
passing
it.)
Return
8521
to
the
original
position
and
tighten
8857
(Shaft).
Loosen
PUK1.4
x
1.880
of
8522
(Stopper),
slide
aside
the
8522,
,
and
raise
8519
(Shaft)
to
release
its
engagement
with
the
Gear
A.
While
keeping
the
proper
relationship
between
the
Gears
A
and
B
(items
(1)
through
(3)
above),
rotate
(8519)
until
8538
(Curtain)
reaches
closest
to
the
Scratched-Line
on
the
Die-Cast
(see®in
the
illustration
in
page
18
),
and
lower
(8519)
until
it
gets
engaged
with
the
Gear
A.
Make
fine
adjustment
on
the
alignment
of
the
Patch
of
8538
and
Scratched-Line
on
the
die-cast
by
adjusting
the
5
holes*
positions.
020-15
Tolerance:
m
Return
8522
(Stopper)
to
the
original
position
and
tighten
PUK1.4
x
1.880.
