Olympus STYLUS-7040 - Names of Parts; Camera Unit

6 EN
Names of Parts
1 Connector cover ..................... p. 11, 12
2 HDMI micro connector .................p. 46
3 Multi-connector ........... p. 11, 12, 45, 47
4 Strap eyelet ....................................p. 7
5 Flash ............................................p. 26
6 Battery/card compartment lock
*1
....................................................p. 10
Camera unit
1
4
2
3
6
5
9
8
8
9
2
3
12
8
9
2
3
12
10
11
7
STYLUS-7040/μ-7040 STYLUS-5010/μ-5010
7 Battery/card compartment cover
.................................................... p. 10
8 Self-timer lamp .............................p. 27
9 Microphone ............................p. 32, 39
10 Lens ............................................. p. 57
11 Tripod socket
12 Speaker
*2
*1
STYLUS-9010/μ-9010 and STYLUS-7040/μ-7040
only
*2
STYLUS-7040/μ-7040 and STYLUS-5010/μ-5010
