Assembly
(Note) The image pickup fields of applicable C-mount video
cameras are as shown on the right.
Field number
22
Trinocular Observation Tube
C-mount video camera
Side port of IX2 series microscope
2/3-inch CCD video
camera
(FN 11)
1/2-inch CCD video
camera
(FN 8)
IX2 Side Port
Double port
adapter
U-DPCAD
C-mount video camera
Clamping
screw
UIS trinocular tube
C-mount
video
camera
C-mount video camera
Double port
adapter
U-DPCAD
Clamping
screw
