Remote Control Range
Point the infrared transmitter of the remote control toward the remote control sensor located at the front
or rear of the main unit and operate.
Reception of the remote control signal should generally be possible within the range illustrated below.
30°
30°
50°
50°
4m / 13.1 feet
4m / 13.1 feet
7m / 23 feet
7m / 23 feet
Remote control sensor
Remote control infrared
transmitter
Side View
Remote control
sensor
Remote control infrared
transmitter
Top View
Note
* Exposure of the main unit’s remote control sensor or the remote control infrared transmitter to bright light or
the obstruction of the signal by an obstacle located in the pathway may prevent operation.
* The remote control will not function when the battery is exhausted.
