OLYS MPPT5010 User Manual

Protection function
1
Battery overvoltage protection
2
Solar panel overvoltage protection
Solar panel voltage>50V: stop charging
Buzzer: Di-Di-Di (1 ring every 2 seconds, half a minute)
Battery low voltage protection
Battery voltage <over-discharge voltage: load off
Buzzer: Dididi--Dididi--Dididi (half minute)
3
Solar panel over-power protection
Limit charging power 130W (12V), 260W (24V)
4
Load overload protection
5
Load short circuit
no protection
6
Overheating protection
7
stop working at 80℃, resume working at 60℃
Technical data
Model
System voltage
Battery range
Max.charge current
Max.load current
Max.PV voltage
Max.PV power
Battery type GEL AGM Flooded LiFePO4(12.8V) Lithium ion(NCM)(11.1V)
Boost charge
Float charge
Equalization charge
Overvoltage shuts down the load
Overvoltage shutdown charging
Overvoltage recovery
Boost charge recovery
Load reconnect level
Battery low voltage alarm
Load disconnect voltage
Temperature compensation
Idle self-consumption
Grounding
Ambient temperature
Dimensions (W x H x D)
Weight
IP level
Accessories (need to be
purchased separately）
MPPT5010
12V/24V Auto recognition
12V: 0-16V /24V:16V-32V
10A
10A
50V
130W/260W
14.3V 14.4V 14.7V
13.8V 13.5V 13.5V
16V
15.5V
13.7V
13.2V
12.5V
11.5V
11V
-3mv/℃/2V Note: Lithium battery has no temperature compensation
<25mA
Positive grounded
-20℃-+50℃
147×97×43mm
0.38kg
IP30
Meter( MT-4-BT)
Bluetooth Dongle(BT10,), freeAPP
Temperature Sensor(RTS)
14.4V
12.6V
14.3V
12.5V
14.6V 14.8V
16V
16V
16V
14V
15.5V 15.5V 15.5V
13.5V
13.7V 13.7V
14.8V 12.8V
13.2V
12.5V
13.2V
12V
12.5V
13.2V
12.5V
11V
11.5V 11.5V 11.5V 10V
11V 11V 11V
9.5V
The following charging voltage parameters and protection voltage parameters are 12V battery system, and the value of 24V
battery system is twice that of 12V system
1. Battery voltage> Load high voltage protection voltage: Load OFF
2. Battery voltage> Overvoltage protection voltage: Off charging
3. Battery voltage> Boost voltage +0.2V for 10 seconds, turn off charging
Buzzer: Di-Di-Di (1 ring every 2 seconds, half a minute)
1.2 times rate current : Turn off the load output after 60 seconds
1.5 times rate current: Turn off the load output after 20 seconds
2 times overload: directly turn off the load output
If the above overload protection occurs, restart the load output after 120
seconds If overload occurs more than 3 times, turn off the load completely.
Manually reset the machine before restarting
No No No
Buzzer: Di--Di--Di (1 time/s, half minute)
