OM SYSTEM OM-5 Quick Start Guide

OM-5 Quick Guide 3
Overview
Front Side
Back Side
Mode dial
Hot shoe
button
(protect)
AEL/AFL/
0
Rear dial
button
Speaker
INFO button
MENU button
Eyecup
Eye sensor
Viewnder
Monitor
(touch screen)
Diopter
adjustment dial
button
button
(playback)
(erase)
OK button
Arrow pad
Fn lever
Mode dial lock
Mode dial
Stereo microphone
Shutter button
(exposure compensation)
button
ON/OFF lever
Self-timer lamp/
AF illuminator
Strap eyelet
Lens release button
Preview button
Front dial

OM SYSTEM OM-5 Specifications

General

Sensor Type	Live MOS
Effective Pixels	20.4MP
Image Processor	TruePic IX
Viewfinder Resolution	2.36 million dots
LCD Screen Size	3.0 inches
LCD Screen Resolution	1.04 million dots
Shutter Speed	1/8000 to 60 sec
Dimensions	125.3 x 85.2 x 49.7 mm
Weight	414 g (body only)
Connectivity	Wi-Fi, Bluetooth
Memory Card Slot	1 x SD/SDHC/SDXC (UHS-II compatible)
Sensor Size	17.3 x 13 mm (Micro Four Thirds)
ISO Sensitivity	ISO 200-25600 (expandable to ISO 64)
Autofocus Points	121 points
Viewfinder Type	Electronic
LCD Screen Type	Tilting Touchscreen
Video Recording	4K UHD at 30p
Continuous Shooting	10 fps (mechanical shutter), 30 fps (electronic shutter)
Image Stabilization	5-axis sensor-shift
Weather Sealing	Yes
Battery Type	BLS-50 Lithium-Ion battery
Battery Life	Approx. 310 shots
Autofocus System	Contrast Detection AF
