Parts Breakdown
Model G368BMF 24271
No. Description No. Description No. Description
1 K Clip 17 Fan Net Cover 33 Screw Foot
2 Shelf 18 Screw 34 Link Bar
3 K Clip Hanging Bar 19 Condenser Fan Motor 35 Lamp Holder
4 Cabinet 20 Screw Cap 36 Lamp Installing Panel
5 Top Cover 21 Fan 37 Hinge Screw
6 Top Strengthen Frame 22 Condenser 38 Gasket
7 Pipe Bafe 23 Screw 39 Down Hinge
8 Compressor 24 Installing Panel Bracket 40 Hinge Cover
9 Light Board 25 Installing Panel 41 Gasket
10 Light Board Panel 26 Outside Water Tray 42 Glass Door
11 Evaporator 27 Installing Panel Bracket 43 Door Handle
12 Inside Water Tray 28 Link Bar 44 Upper Hinge
13 Dry Filter 29 Down Shutter Panel 45 Hinge Screw
14 Evaporator Fan Motor 30 Switch 46 K Clip Hanging Bar
15 Screw 31 Digital Temp Controller
16 Evaporator Fan Cover 32 Castor Installing Panel
