Parts Breakdown
Model D768BM2F 24273
No. Description No. Description No. Description
1 Back Cover 21 Door Switch 41 Wire Protector
2 Drain-Water Hose 22 Down Hinge 42 Cover of Wire Box
3 Caster 23 Down Hinge Axis 43 LED Light
4 Exterior Water-Tray 24 Axis Cover 44 Return Pipe Cover
5 Compressor 25 Door 45 Interior Water Tray Heater
6 Dry Filter 26 Door Gasket 46 Water Drain Heater
7 Fixer for Dry Filter 27 Top Hinge (Left and Right) 47 Interior Water Tray
8 Condenser Fan Motor 28 Top Light Panel 48 Evaporator
9 Blade of Condenser Fan Motor 29 Light Frame 49 Defrost Heater
10 Cover of Condenser Fan Motor 30 Top Light 50 Nut
11 Condenser 31 Light Outlet 51
Transformer for Glass Door
Heater
12 Track for Assemble Panel 32 Assemble Panel of Light 52 Bolt
13 Support Connector 33
Cover of Evaporator Fan
Motor
53 Transformer Fix Panel
14 Support Panel for Leg 34 Supporter for K Clip 54 Ballast Resistor for LED Light
15 Limiter of Assemble Panel 35 K Clip 55 Ballast Resistor for Top Light
16 Digital Cover 36 Fixer for Evaporator Cover 56 Cabinet
17 Grill 37 Evaporator Cover 57 Shelf
18 Digital Temperature Controller 38 Fan Motor Left Panel 58 Assemble Panel
19 Light Switch 39 Evaporator Fan Motor 59 Assemble Puller
20 Power Switch 40 Fan Motor Right Panel 60 Compressor Starter
