7. Southern Hemisphere configuration
The south hemisphere configuration is to be used below the
equator. In the southern hemisphere, the sky “rotates” on the
opposite direction. For that reason, it is necessary to add an
additional arm (C) to the mount and invert the sense of the
timer’s movement.
7.1. Release and remove the two thumbnuts (#6 Side A).
7.2. Release and unscrew the timer screw with washer (#10)
using a Philips-style screwdriver (not included).
