Omnimount OC100T User Manual

PN: 888-61-033-W-01 RevD
9
Screws / Hardware for Flat Panel
Part # Qty Description
M-A 4 Philips screws M4 x 15mm
M-B 4 Philips screws M4 x 30mm
M-C 4 Philips screws M5 x 15mm
M-D 4 Philips screws M5 x 30mm
M-E 4 Philips screws M6 x 15mm
M-F 4 Philips screws M6 x 30mm
M-G 4 Philips screws M8 x 15mm
M-H 4 Philips screws M8 x 30mm
M-I 4 Round Spacers: M6-M8 x 5mm
M-J 4 Round Spacers: M6-M8 x 10mm
M-K 4 Round Washers: M4-M5
M-L 4 Round Washers: M6-M8
Part # Qty Description
W-A 2 Lag Bolts 8mm
W-B 2 Steel Washer
W-C 2 Wall Anchor
Contents
Part # Qty Description
1 1 Wall Plate
2 1 Right Vertical Rails
3 1 Left Vertical Rail
4 1 Locking Bar
5 1 Bubble Level
6 2 Tilt Pins
Wall Kit
CONTENTS
2
1
4
M-A M-B M-C
W-A W-B
M-D
M-E M-F M-G M-H
M-I M-J M-K M-L
W-C
5
3
6

Omnimount OC100T Specifications

General

Brand	Omnimount
Model	OC100T
Category	TV Mount
Language	English
