PN:888-60-550-M-02 RevF
9
SCREWS/HARDWARE FOR FLAT PANEL 695-479-00
Part # Qty Description
M-A 4 Philips Screws M4 x 12mm
M-B 4 Philips Screws M4 x 45mm
M-C 4 Philips Screws M5 x 12mm
M-D 4 Philips Screws M6 x 12mm
SCREWS/HARDWARE FOR WALL MOUNTING 697-610
Part # Qty Description
W-A 2 Lag Bolt
W-B 2 Wall Anchor
SCREWS/HARDWARE FOR PRODUCT 697-704
Part # Qty Description
P-A 4 V200A Adapter
P-B 4 Vesa Adapter Screws
Contents
Part # Qty Description
1 1 Wall Plate
2 1 Wall Plate Cover
3 1 Arm Assembly (with cable management)
4 1 Monitor Plate
5 1 Monitor Plate Screw/Washer
6 1 Tilt Tension Handle
NTENTS
M8M5KIT
Qty Description
4 M5x20mm
4 Thread Reducer
M-A
M-B M-C
W-A
W-B
P-B
2
1
3
4
5
6
P-A
M-D
